Description
Passive Range – Passive Timber Frame Building Blackheath 10.9 m x 16.7 m rtfblv2233
Timber Frame Base size – 10.9m x 16.7m
Timber Frame Base size – 35.76ft x 54.79ft
Size With Decking – 10.9m x 16.7m
Entrance Decking – 3.3m x 2.6m
Side decking – 2.34m x 6.15m
Residential Door size – 1x 110cm x 200cm (outside)
Residential Door size – 11x 87cm x 193cm (inside)
Residential Window size – 4x 90cm x 130cm (ground floor)
Residential Window size – 3x 100cm x 230cm (ground floor)
Residential Window size – 1x 225cm x 230cm (ground floor)
Residential Window size – 1x 300cm x 130cm (ground floor)
Residential Window size – 1x 400cm x 230cm (ground floor)
Residential Window size – 1x 225cm x 160cm (ground floor)
Residential Window size – 2x 90cm x 130cm (first floor)
Residential Window size – 1x 90cm x 90cm (first floor)
Residential Window size – 4x 225cm x 130cm (first floor)
Residential Window size – 1x 225cm x 200cm (first floor)
Residential Window size – 1x 90cm x 200cm (first floor)
Residential Window size – 2x 225cm x 150cm (first floor)
Entrance – 2.4m x 2.0m (ground floor)
Storage – 4.5m x 2.5m (ground floor)
Bathroom – 3.5m x 3.8m (ground floor)
Lounge Area – 5.25m x 7.0m (ground floor)
Kitchen/Dining – 4.3m x 6.15m (ground floor)
Garage – 4.5m x 6.5m (ground floor)
Bedroom 01 – 4.3m x 3.82m (first floor)
En-Suite – 3.5m x 2.0m (first floor)
Dresser – 1.55m x 1.66m (first floor)
Bedroom 02 – 4.5m x 4.5m (first floor)
Bedroom 03 – 4.5m x 4.5m (first floor)
Bathroom – 2.4m x 2.0m (first floor)
Utility – 2.7m x 2.0m (first floor)
External Ridge height – 8.51m
Internal Ceiling height – 2.65m
Roof Thickness – 47cm
Wall thickness – 47cm
