Glamping Camping Pods are now here to stay, quality levels as always start with cheap and cheerful and go to the sublime.
Sadly, the gene of design seems not to fall far from the tree, and sadly because of this, designs of camping pods tend to be copies of the first originals, and these new designs tend to be somewhat a cut down version to win favor to their customer with lower pricing.
However, as we always say, buy cheap buy twice.
Many camping sites, holiday parks, fisheries, hotels, B&B’s are now looking for something completely different, they want to stand out and offer not just tube like structures, but offer more comfortable surroundings to their guests.
Many now want their glamping camping units to conform to building full building regulations, have fitted CE certified windows and doors, and be completely portable and built to an extremely high standard.
Therefore, as always we have tried our best to design a camping, glamping unit that is manufactured to a very, very high standard, which ticks all the boxes, and crosses all the T’s.
Our Highly Insulated Timber Frame Camping Cabins do not just conform to the UK building regulations, they actually exceed it.
Our New Timber Frame Insulated Glamping Units are not just built to be pretty, they are built to last, with their Northern Siberian External Larch Cladding, massive insulation properties, certified CE residential windows and doors.
Your New Camping Fully Insulated Cabin could be built with this specification.
Exterior walls:
- Vertical larch panel – oiled – already made panels;
- Horizontal impregnated battens for vertical panel – already made panels;
- Vertical impregnated battens 20x45mm c/c600 for air gap – already made panels;
- Tyvek film – already made panels;
- Gypsum plate 9.5mm as wind barrier – already made panels;
- Segments of wooden framework 45x195mm c/c600 – already made panels;
- KNAUF insulation 200mm – in free lengths;
- Plastic film 0.2mm – in free lengths;
- Battens 45x45mm c/c600 for cables and pipes – in free lengths;
- KNAUF insulation 50mm – in free lengths;
- 5mm gypsum plate/13mm wooden not treated panel (25%) – in free lengths.
Inside walls:
- 5mm gypsum plate/13mm wooden not treated panel (25%) – in free lengths.
- Segments of wooden framework 45x95mm c/c600 and for bearing walls 45x145mm c/c600 – already made panels;
- KNAUF insulation 100/150mm – in free lengths;
- 5mm gypsum plate/13mm wooden not treated panel (25%) – in free lengths.
Floor:
- 22mm chipboard – already made panels;
- Wooden framework 45x195mm c/c600 – already made panels;
- KNAUF insulation 200mm – already made panels;
- 12mm plywood with laminated bottom side – already made panels;
Roof:
- PVC membrane TechnoNICOL – in free lengths;
- 12mm plywood with lamination on one side – in free lengths;
- Battens 45x45mm c/c600 along roof rafters for air gap – in free lengths;
- Diffusion film Tyvec Pro – in rolls;
- Bended glue-lam beams 100x440mm (140mm visible) c/c1200 (centers due to plywood width) – in free lengths;
- Precut rafters 45×145+45x145mm c/c600 (the top matches with glue-lam top) – in free lengths;
- KNAUF insulation 300 mm in the rafters – in free lengths;
- Plastic film 0.2mm – in free lengths;
- 6,5mm plywood – in free lengths;
- 6mm gypsum plate/13mm wooden not treated panel (25%) – in free lengths.
Windows and doors:
- Windows (3 pcs) wooden frame windows with triple glass package, European-type (opening inwards, with handles), painted.
- Outside doors (1pcs.): wooden entrance doors with insulated plate triple glazing with 3-plug quality locks and handles, impregnated, primed and painted.
- Wooden inside doors (2 pcs) made glued pinewood with impregnated MDF fillings, with simple locks (without handles), primed and painted. Sliding doors.
This kind of quality engineered timber frame glamping cabin is not available anywhere on the web, which is why logcabins LV is the leader, not the follower.
